Ürün Tanımı


  • Consumes one tenth the standby power of general crystal resonators (with a load capacitance of 12.5 pF)
  • Excellent low drive level characteristics.
  • Complies with RoHS directive
  • Halogen free


Nominal Frequencyf_nom32.768kHz
Frequency Tolerancef_tol±5 x 10-6, ±10 x 10-6, ±20 x 10-6

※Please contact us for inquiries regarding available tolerance.

Turnover TemperatureTi+25±5ºC
Parabolic CoefficientB(−0.033±10%) x 10-8/ºC2
Load CapacitanceCL3.7pF , 4.4pF , 6.0pF

※Please contact us for inquiries regarding available CL.

Motional Resistance(ESR)R165kΩ max.
Absolute Maximum Drive LevelDLmax.1.0μW
Drive LevelDL0.01μW
Shunt Capacitance00.9pF typ.
Frequency Ageingf_age±3 x 10-6
Operating TemperatureT_use−40ºC to +85ºC
Storage TemperatureT_stg−55ºC to +125ºC

Ürün Detayları

  • Area (mm2): 10,5
  • Frequency Tolerance: ±5 x 10-6, ±10 x 10-6, ±20 x 10-6
  • Height (mm): 1,4
  • Load Capacitance: 3.7pF, 4.4pF, 6.0pF
  • Nominal Frequency: 32.768kHz
  • Type: Low Power
